HSM Powerline SP 4040 V 1/8 x 1-1/2 Inch Shredder Baler

  • SKU: HSMSP4040V-2515111124
  • Security: Level 3/P-4
  • Sheet Capacity: 100 sheets*
  • Throat: 16.85"
  • GTIN/UPC: 096224645936
  • Mfr. Part No.: HSM2515

This product has limited availability and/or is build-to-order.
Please call us at (800) 243-9226 or fill out the Request a Quote form, below.

Request A Quote
Need Advice?
Call us at (800) 243-9226

Basic Specs of the HSM SP 4040V (1/8 x 1-1/2 inch) Shredder Baler

  • Shred Size: 1/8 x 1-1/2 inches
  • Throat Width: 17 inches
  • Capacity: Up to 100 sheets*
  • Speed: 8.66 mm per second
  • Power: 400V/50Hz/6200W
  • Pressing Power: 4 t
  • Shipping Weight: 1,625 lbs.
  • Dimensions: 44"W x 86"D x 78"H
  • Baler Dimensions: 24"W x 20"H x 16"L

Features of the HSM SP 4040V Shredder Baler

  • Display to indicate "bale ready"
  • Keypad for continuous and reverse operation
  • Integrated, manual oiler for cutting unit (particle cut only)
  • Press with modern control unit
  • Removal trolley for box or waste bag (standard equipment: 5 boxes, 5 plastic bags, bag holder)
The HSM SP 4040V shredder/baler combination unit breaks down your paper materials into security level 3/P-4 pieces to produce perfect bales.

Video Demo of the HSM SP 4040V 0.15"x1.6" Shredder Baler


Description of the HSM SP 4040V 0.15"x1.6" Shredder Baler

Shredding and pressing at the same time, the HSM SP 4040 V is the definition of efficient. Capable of shredding continuously, this document shredder offers a keypad for both continuous and reverse operation.

The HSM SP 4040 V will also automatically switch into reverse should a jam occur. The shredder will continue in reverse until the problem is remedied. Load your documents onto the spacious loading table while the electric conveyor belt pulls your materials into the shredder. As your documents fall, they are broken down by the solid steel cutting rollers into 1/8 x 1-1/2 inch particles.

Satisfying level 3/P-4 security requirements, the 4040 V shreds at a speed of up to 8.66" per second. The HSM SP 4040V will handle an assortment of materials, from paper books, reams of paper, three-ring binders, and cardboard. Once your materials are destroyed and fall into the pressing chamber, the baling process begins. Your shredded items are pressed into 15 ¾" L x 23.6" W x 19.7" H (400,00 mm L x 600 mm W x 500 mm H) bales. This pressing module features a modern control unit and removable trolley for your boxed or bagged waste. As a bonus, the convenient display indicates when your baled product is ready!

Easy to maintain, the HSM 4040 V comes with an integrated, manual oiling system for the cutting unit. It's compact, vertical design makes it the perfect solution for any crowded warehouse or production area.

* Please note, capacity varies with grain, size, quality & paper weight and sufficient power supply.
** Please use actual HP as a specification for determining value. Use of Peak HP is for comparison purposes only where other than Actual HP is used.

Manufacturer Name HSM
Throat Size/Feed Opening 16.85 inches
Shred Speed 8.66"/s
Shred Size 1/8 x 1-1/2 inches
Security Level Level 3/P-4
Cut Type Cross Cut
Sheet Capacity Up to 100 sheets*
Shreds Credit Cards? Yes
Shreds Paper Clips? Yes
Shreds Staples? Yes
Driving HP 8.31 HP
Disclosures Capacity varies with grain, size, quality & paper weight and sufficient power supply.
** Please use actual HP as a specification for determining value. Use of Peak HP is for comparison purposes only where other than Actual HP is used.
Continuous Motor Yes
Model # 4040V
Weight 1,625 lbs.
Height 78 inches
Width 44 inches
Depth 86 inches
Voltage Power: 208V / 60 Hz
Warranty Click here to view warranty
Shipping Weight 1,625 lbs.
