Intimus HDD Granulator
Intimus HDD Granulator
Intimus HDD Granulator

Intimus HDD Granulator
Intimus HDD Granulator
Intimus HDD Granulator

Intimus HDD Granulator

  • SKU: SCHHDDGRANULATOR
  • Security: Up to H-5
  • Throat: 13"

This product has limited availability and/or is build-to-order.
Please call us at (800) 243-9226 or fill out the Request a Quote form, below.

Request A Quote
Need Advice?
Call us at (800) 243-9226

Basic Specs of the Intimus HDD Granulator

  • Screens (HDD): 0.55 in (Throughput: HDD up to 70 units/h, approx. 81.6 lbs/h) (Security level: H-5, O-3, T-4)
    0.47 in (Throughput: HDD up to 40 units/h, approx. 48.5 lbs/h) (Security level: H-5, O-3, T-4)
    0.39 in (Throughput: HDD up to 25 units/h, approx. 30.9 lbs/h) (Security level: H-5, O-4, T-5)
    0.31 in (Throughput: HDD up to 20 units/h, approx. 22 lbs/h) (Security level: H-5, O-4, T-5)
    w/o screen (Security level: H-3, O-2, T-2)
  • Intake Width HDD: 13"
  • Bin Volume 63.4 gallons
  • Shredding Material: HDD, Floppy disk, Data tape, Plastic card, CD / DVD / Blu-ray

Features of the Intimus HDD Granulator

  • Industrial application for the destruction of HDDs up to 5.25 inch.
  • Can even handle enterprise HDDs and HDDs with server frame.
  • Meets highest security levels - available screens allow you to cover security levels up to H-5.
  • More screens available on request.
  • Easy waste disposal thanks to the mobile standard waste bin with 63 gallon capacity.
  • Solid steel housing and a powerful motor guarantee a long product lifetime.
  • Made in Germany is a promise of quality and durability.

Description of the Intimus HDD Granulator

Security requirements for the destruction of sensitive data are increasing all over the world. What was sufficient yesterday may not be sufficient tomorrow. A future-proof investment means having a flexible solution: With the intimus HDD Granulator, security levels of produced particles and throughput can be varied by simply changing the screens. Thanks to its unique hybrid technology, the intimus HDD Granulator combines the advantages of a shredder and a disintegrator. Perfect for reliable and economical shredding of HDDs, floppy disks, data tapes, plastic cards, CDs/DVDs and Blu-rays. The sturdy rectangular steel tube base frame accommodates a standard 63 gallon waste bin to collect the shredded material for direct disposal.

Manufacturer Name Intimus
Screens (HDD) 0.55 in (Throughput: HDD up to 70 units/h, approx. 81.6 lbs/h) (Security level: H-5, O-3, T-4)
0.47 in (Throughput: HDD up to 40 units/h, approx. 48.5 lbs/h) (Security level: H-5, O-3, T-4)
0.39 in (Throughput: HDD up to 25 units/h, approx. 30.9 lbs/h) (Security level: H-5, O-4, T-5)
0.31 in (Throughput: HDD up to 20 units/h, approx. 22 lbs/h) (Security level: H-5, O-4, T-5)
w/o screen (Security level: H-3, O-2, T-2)
Shredding Material HDD, Floppy disk, Data tape, Plastic card, CD / DVD / Blu-ray
Intake Width HDD 13"
Bin Volume: 63.4 gallons
Noise Level (Idle Operation) 70 dB(A)
Motor Power Consumption 5.9 (HP)
Power Supply 400 V/ 50 Hz
Disclosures * Capacity varies with grain, size, quality & paper weight and sufficient power supply.
** Please use actual HP as a specification for determining value. Use of Peak HP is for comparison purposes only where other than Actual HP is used.
Continuous Motor Yes
Weight 2,336.9 lbs.
Height 83.9"
Width 54.3"
Depth 30.3"
Warranty Click here to view warranty
