Standard PF-P3300 Automatic Air-Feed Paper Folder
- SKU: SDMPFP330
- Max Paper Weight: 157 gsm
- Max Paper Size: 12" x 17"
- Adjustment: Manual
- Feed Type: Air
- Fold Types: Letter, Half, Z-fold, Double Parallel, Gate
- GTIN/UPC: 096224642775
- Mfr. Part No.: PF-P3300
- Sale price
- Sale price
- $8,690.00
- Unit price
- per
Call us at (800) 243-9226
Eligible for FREE FREIGHT SHIPPING within the contiguous United States.
This product requires Liftgate Service. If you don't have a loading dock or a forklift available to move the delivery off of the truck, please
add Liftgate Service to your cart.
If applicable, there is an additional charge for freight-related residential delivery.
Basic Specs of the Standard PF-P3300 Paper Folder
- Speed: Up to 15,000 sheets/hour
- Fold Patterns: Single, Double Parallel, Short Fold, Accordion, Letter, Open Gate
- Feeder Stack Height: Up to 1.96 inches
- Minimum Sheet Size: 4.93 inches x 5.12 inches
- Maximum Sheet Size: 12.2 inches x 17 inches
- Sheet Weight Range: Normal paper, glossy, and coated; 52 gsm to 157 gsm
- Sheet Feeding System: Air rotor system
Features of the Standard PF-P3300 Paper Folder
- 4 preset sheet sizes and 10 preset fold patterns.
- Quiet operation for use in sensitive areas.
- Manual fold plate adjustment with power-assist function.
- Digital 4-digit counter (ascending and preset counter).
- Paper jam detection.
- Test fold button.
- Stack roller position indicator.
Fold Types for the Standard PF-P3300
There are six different fold types available for the PF-P3300:
(1) Letter fold (Tri-fold, C-fold),
(2) Half-fold (Single fold),
(3) Z-fold (Accordion, Zig Zag),
(4) Double-Parallel,
(5) Gate (Open Gate, Brochure), and
(6) Engineering (Short Z, Fold Out, Half Accordion)
(1)
(2)
(3)
(4)
(5)
(6)
Video of the Standard PF-P3300 Paper Folder
Description of the Standard PF-P3300 Paper Folder
The PF-P3300 Paper Folder is a compact system packed with high tech features that make it a quiet and optimal resource for almost any location in which single sheet folding is required. Though it is equipped with numerous features and functions, the PF-P3300 paper folder excels in ease of use thanks to its innovative and proprietary rotary vacuum feed system. This not only eliminates most common jamming issues, but it also makes the machine operate almost silently, and function without the need to adjust the feed to the different feed stocks. The pump is small and quiet and does not make the machine an oversized unit. Instead, it is considered a desktop machine, but one that can handle up to 240 folds per minute. The PF-P3300 Paper Folder handles paper sizes from 5" x 5" to 12" x 17", and at weights of 14 pound bond to 60 pound cover stock. The tray can hold up to 550 sheets or 2.2" of paper, and it will perform a range of different folds that include the standard half fold, letter folds, double parallel folds, Z folds, gate folds, and engineering folds. There are also ten programmable folds that allow you to lock in your most common, custom jobs. There are many other features on the PF-P3300 Paper Folder, and these include the adjustable speed controls, the delay feed mode, a jam detection function, a single test page, a digital counter and easy access maintenance.
When the rollers require cleaning or repair, a single access panel allows the user to easily remove or replace the pieces. Essentially, the PF-P3300 paper folder is one of the simplest folding machines for those who need to tackle large numbers of single sheet documents. It is, however, innovative in that it uses the suction feed unit that prevents jamming and does not leave marks on the sheets. The suction unit is quiet enough to use in even a small office setting, and yet many print shops and copy centers can benefit from the speed and adjustability of this model. It is a solid solution for those folding many types of paper, and it cuts down on the amount of labor involved in setting up and monitoring the progress of even complex folding jobs.
Strengths
- Powerful air feed system in a small, tabletop folder.
- Unique design provides mark-free finished products.
- Rotary vacuum system eliminates requirement to adjust for different stock.
Fold Types for the Standard PF-P3300 Automatic Air-Feed Paper Folder
 | Click Here for the Paper Weight Conversion Chart |
Please select your preferred download file from below.
For additional resources, please see:
- Our Paper Weight Conversion Chart for paper weight and paper stock information.
- Our Paper Folder Fold Type Guide to learn more about different fold types.
| Manufacturer Name | Standard |
|---|---|
| Model # | PF-P3300 |
| Feed Type | Air-fed |
| Fold Adjustment Setting | Automatic fold adjustment |
| Feed Tray Capacity | Up to 550 |
| Fold Speed | 15,000 sheets/hour |
| Fold Types | Half Fold, Letter Fold (Tri), Z Fold, Gate Fold, Double Parallel Fold, Engineering Fold (Short Z) |
| Pre-programmed Standard Folds | 6 |
| Programmable Presets | 18 |
| Counter | Yes |
| Accepted Paper Sizes | 5" x 5.2" to 12" x 17" |
| Accepted Paper Weights | 14 to 60 lbs. |
| Weight | 116 lbs. |
| Height | 25 inches |
| Width | 42 inches |
| Depth | 20 inches |
| Voltage | 120 Volts; other voltages available |
| Warranty | Click here to view warranty |
| Shipping Weight | 116 lbs. |
